All Mountain 7 Carbon Tschugg Signature
€6.999,00
Legendary performance meets iconic design. The Tschugg Signature All Mountain e bike fully delivers 110 Nm power, 800 Wh range and world-class race components.
- Motor:
- HEPHA P110 (110 Nm / 250 W / 25 km/h)
- Battery:
- HEPHA BT-800BH (800 Wh)
Which frame size fit me?
Which frame size fit me?
Leasing with one of our partners
Lease your new Hepha with JobRad and save up to 40% with tax-free benefits. Just select your dream bike and approved accessories, and place your order.
Learn moreBikeleasing-Service lets you lease your bike with a tax advantage. You can find out whether your employer offers Bikeleasing-Service from your HR department.
Learn moreDeutsche Dienstrad-Service lets you lease your bike with a tax advantage. You can find out whether your employer offers Deutsche Dienstrad-Service from your HR department.
Learn moreBusinessBike-Service lets you lease your bike with a tax advantage. You can find out whether your employer offers BusinessBike-Service from your HR department.
Learn moreFinancing with one of our partners
Financing with PayPal
Pay in instalments of up to 24 months via PayPal.
Financing with Zinia
Finance your bike and accessories with Zinia, offering flexible installment plans from 6 to 48 months.
Financing with Klarna
Klarna offers direct payments, pay later options, or installment plans ranging from 6 to 36 months.
Financing with Alma
2 to 4 interest-free installments for amounts from 50 to 5,000 euros.
Click & Collect at your local dealer
When you order a bike from hepha.com, we'll ship it for free to a dealer of your choice through our Click & Collect service. Once your bike arrives, the dealer will reach out to arrange a pickup time. Enjoy personalized assistance, test rides, and expert advice with this service. Learn more
All Mountain 7 Carbon Tschugg Signature
×
Specification
E-Bike System
Motor
HEPHA P110 (110 Nm / 250 W / 25 km/h)
Battery
HEPHA BT-800BH (800 Wh)
Display
HEPHA SC-201 1.96'' Display
Frame
Frame
Hepha Monocoque Full Carbon Frame, 4-Link Virtual Pivot
Suspension
Fork
Suntour Durolux 38
Shock
Suntour TriAir2
Shifting
Derailleur
SRAM / RD-GX-E-B1 / 12-Speed
Shifters
SRAM / EC-AXS-POD-D1 / 12S
Cassette / Sprocket
SRAM / CS-XS-1275-A1 / 10-52T
Chain ring
Alloy BCD104, 36T,CL=50MM
Brakes
Brake (f / r)
Magura Gustav Pro
Brake disc (f / r)
203/180 mm
Brake levers
Magura Gustav Pro
Wheels
Tires
Schwalbe / 29” x 2.5”
Rims
Newmen Beskar 30
Hub (f/r)
Newmen
Steering & Seating
Handlebar
SQLab 30X / Width 780mm / Barbore: 31.8mm
Grips
SQLab 70X 2.0 Pro medium
Stem
SQLab 80X / E 35mm / C 31.8mm
Seat post
ISTOS E-Dropper Post, Travel: 125mm, 31,6mm
Saddle
SQLAB Sadlle 611 Ergowave
Components
Front light
Rear light
Carrier
Weight & Class
Perm. total weight
150 kg
Bike weight
Category
4
Frame & Geometry
Frame Size
Geometry
| No. | Measurement | M | L |
|---|---|---|---|
| A | Frame Height | 440 mm | 480 mm |
| B | Seat Tube Angle | 68.5° | 68.5° |
| C | Fork Offset | 66 mm | 42 mm |
| D | Seat Angle | 74° | 74° |
| E | Head Tube Length | 110 mm | 124 mm |
| F | Head Tube Angle | 66° | 66° |
| G | Top Tube Horizontal | 629 mm | 655 mm |
| H | Chain Stay Length | 458 mm | 458 mm |
| I | Bottom Bracket Drop | 20 mm | 20 mm |
| J | Wheelbase | 1,225 mm | 1,249 mm |
| K | Stack | 617 mm | 629 mm |
| L | Reach | 453 mm | 475 mm |
| M | Standover Height | 773 mm | 806 mm |
| Seat Height Min | 555 mm | 595 mm | |
| Seat Height Max | 820 mm | 860 mm |
The e-bikes illustrated may differ in individual details from the standard model and may show special equipment at an extra charge. All information on the scope of delivery, appearance, performance, dimensions and weights of the bikes is non-binding and subject to component availability, errors, printing, typesetting and typing errors; we reserve the right to make changes at any time. No rights can be derived from incorrect information. Please note that model specifications may vary from country to country; for more information, please contact your authorized dealer. *All prices are recommended retail prices including the applicable statutory VAT.
